P10 Full color Pollution Parameter LED Display Board

Send Inquiry

Request To Call Back

P10 Full color Pollution Parameter LED Display Board

Price 98999.0 INR/ Number

Get a Price/Quote

MOQ : 1 Unit Number

P10 Full color Pollution Parameter LED Display Board Specification

Screen Dimension
As per requirement (customizable), standard sizes available

Usage
Outdoor Pollution Parameter Information Display

Power Consumption
Max 800W per sqm Ampere

View Angle
Horizontal 120 , Vertical 60

Working Temperature
-20 C to +60 C Celsius (oC)

Size
Customizable

Tube Chip Color
Full Color

Application
Air Quality Monitoring, Environmental Display, Public Spaces

Protection Level
IP65, IP66

LED Type
DIP/High-brightness LED

Display Function
Video

Control Mode
PC/Cloud/Remote Control

Input Voltage
AC 230V 10%, 50/60 Hz Volt (V)

Brightness
5500 cd/m cd/m sq

Pixels
P10 (10mm pixel pitch) Pixel (P)

Power Rating
3A - 100 WATT TO 600 WATT

Warranty
1 YEAR + EXTENDED

Rated Voltage
230 VAC Volt (V)

Usage & Applications
INDOOR/OUTDOOR

Operating Temperature
-10 TO 55 Celsius (oC)

Cable Type
COPPER SINGLE PHASE 3 CORE

Phase
SINGLE PHASE 3 CORE

Display Type
INDOOR/OUTDOOR : P010

Rated Current
3AMP Ampere (amp)

Frequency
50 Hertz (HZ)

Features
IP 65 CABINET/ FAST SERVICE/QUALITY PRODUCT/LESS MAINTNENCE/WATERPROOF/SUITABLE FOR ALL COMMUNICATION PROTOCOL /CUSTOMIZES SIZE AND SOFTWARE

Material
TSS MAS P010SR

Conductor
COPPER SINGLE PHASE 3 CORE

Font Size
Adjustable

Communication Interface
RS232/RS485, Ethernet, Wifi, GSM (optional)

Refresh Rate
1920 Hz

Operating Humidity
10% ~ 90% RH

Display Content
PM2.5, PM10, Temperature, Humidity, CO2 & more

Mounting Type
Wall Mounted / Pole Mounted

Data Update Frequency
Real-time / User defined

Module Resolution
32x16 dots (standard P10 module)

Frame Material
Powder coated MS/Aluminium cabinet

P10 Full color Pollution Parameter LED Display Board Trade Information

Minimum Order Quantity
1 Unit Number

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Per Month

Delivery Time
1 Week

Sample Available
Yes

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
Thermocol (As per Market availability), Wooden Crate

Main Domestic Market
All India

About P10 Full color Pollution Parameter LED Display Board

Introducing the Premier P10 Full Color Pollution Parameter LED Display Board - a magnificent new release designed for advanced air quality monitoring in public and industrial spaces. Featuring a Special Rate and the lowest price for this high-quality, fully customizable display, it operates on a Prime RS232/RS485, Ethernet, Wifi, and optional GSM communication interface. Real-time data such as PM2.5, PM10, CO2, temperature, and humidity are vividly presented with a high refresh rate and adjustable font sizes. Durable powder-coated MS/aluminium cabinet, waterproof IP65/IP66 protection, and superb brightness make it ideal indoors or outdoors across India.

Versatile Application & Robust Build

P10 Full Color Pollution Parameter LED Display Board is suitable for both indoor and outdoor settings such as air quality monitoring stations, public squares, and environmental displays. Its powder-coated MS or aluminium cabinet assures durability, while IP65/IP66 protection makes it resilient against harsh weather. This magnificent device employs high-brightness LEDs and customizable screen size, ensuring clear visibility and adaptability for various application areas.

Logistics & Packaging: Seamless Experience

Each unit is securely packaged to ensure safe arrival. Shipped promptly using reliable logistics channels, you can expect swift processing of your order. Payment terms are flexible and designed for your convenience, and sample units are available upon request to validate your requirements. The product is dispatched from India, meeting industry standards for hassle-free delivery and installation.

FAQ's of P10 Full color Pollution Parameter LED Display Board:

Q: How does the P10 Full Color Pollution Parameter LED Display Board update and display pollution data?

A: The display board updates pollution data in real time or at user-defined intervals, utilizing multiple communication interfaces such as RS232/RS485, Ethernet, Wifi, and optional GSM for seamless integration and consistent monitoring.

Q: What key parameters can the display board show in public spaces?

A: The device can show PM2.5, PM10, temperature, humidity, CO2 levels, and more, delivering valuable information to the public and supporting environmental awareness initiatives wherever it is installed.

Q: Where can the P10 LED Display Board be used?

A: It can be wall-mounted or pole-mounted in indoor or outdoor locations, such as public squares, industrial complexes, educational institutions, and air quality monitoring sites across India.

Q: What is the process for customizing the screen dimensions and display content?

A: You can specify your requirements, including size, content type, and data frequency. The manufacturer will tailor the display to match your needs, ensuring optimal performance and information visibility.

Q: What material features ensure the longevity of the P10 Display Board outdoors?

A: The board uses a powder-coated MS/aluminium cabinet and is rated with IP65/IP66 protection, making it waterproof, dustproof, and durable against changing weather conditions.

Q: How can I benefit from having a pollution parameter display board?

A: Installing this device enables continuous environmental monitoring, timely public alerts, and increased air quality awareness, helping organizations comply with regulations and optimize safety for all.

Q: When can I expect my shipment after placing an order?

A: Orders are processed quickly, and products are shipped using trusted logistics partners. The estimated arrival time depends on your location in India and order quantity.
